60A PWM Solar Panel Charge Controller 12V 24V, Max 48V 1560W Input

Regular price $29.99
Sale price $29.99 Regular price
Unit price
About this item

  • Compatibility & Power: This 60 Amp charger is compatible with both 12V and 24V systems, supporting 12V (780W) / 24V (1560W) inputs to meet different charging needs.
  • INTELLIGENT CHARGING & MONITORING: The controller adopts four-stage PWM charging technology, including Boost, ABS, Equalization and Float, to ensure that the battery is charged efficiently and safely. The backlit LCD display shows the charging and discharging parameters of PV, battery and load in real time, making it easy for users to know the status of the system at any time.
    Features: The controller is equipped with charging and discharging current, charging and discharging energy recording function, which is convenient for users to analyze the system usage. In addition, it supports multiple types of lead-acid batteries (OPEN, AGM, GEL) and is equipped with multiple load timers to ensure accurate battery management.
    Comprehensive protection: The controller provides dual MOSFET reverse current, overheating, undervoltage discharge, short circuit, open circuit, overload and overcharge protection to ensure safe and stable operation of the system under various conditions. Especially, when the battery voltage is lower than 8V, the controller will automatically shut down to protect the battery life. Suitable for a wide range of environments such as residential, industrial and commercial.
Compare Ask a question

Ask a Question

* Required fields

Size guide Share
  • Estimated Delivery:Jul 20 - Jul 24

  • Free Shipping & Returns: On all orders over $100

60A PWM Solar Panel Charge Controller

60A PWM Solar Panel Charge Controller 12V 24V, Max 48V 1560W Input

Regular price $29.99
Sale price $29.99 Regular price
Unit price
Description
Shipping and Refund
Warranty Policy

Features

  • This solar power regulator protected with the moisture-tight coating, minimizing damage from humidity and from nesting insects. Suitable for farm solar power system, solar street light, solar patio light, solar billboards, outdoor camping solar system, ship solar system.
  • Fit for Lead-acid batteries(OPEN,AGM,GEL) with multiple load modes.
  • Automatically manage the working of solar panel and battery in solar system.
  • ADD features: Charge and Discharge Current, Charge and Discharge energy recording function.
  • Dual MOSFET Reverse current, protection from lightning strike.
  • Automatic Induction: It will be auto open or close the load when you set the timer to be Light and Time mode.
  • Dual USB supply power to two mobile phones, tablet PCs, and other devices that require max 5V 2.5A power.


Eight PWM Charge Controller Protection:

  • Dual MOSFET Reverse current / Overheat protection
  • Under-voltage discharge protection / Short-circuit protection
  • Open-circuit protection / Over-load protection
  • Over-charging protection / Power off memory protection
  • Suitable for farm solar power system, solar street light, solar patio light, solar billboards, outdoor camping solar system, ship solar system.
60A PWM Solar Panel Charge Controller

Common Q&A

Your satisfaction is our priority.

How to install?

A: (1)Battery --->(2)Solar panels ---> (3)DC load. Disconnect order is (1)DC load --->(2)Solar panels ---> (3) Battery

Q: What battery type is this controller supported?

A: Pay attention to this regulator is only suitable for lead acid batteries: OPEN, AGM, GEL, not for nickel hydride, lithium, ions, or other batteries.

Q: Why the LCD screen become blank?

A: When the battery voltage is too low, the controller will stop to output ( ≦ 8V, controller turns itself off, LCD is blank, ≦ 10.7V (default), 12V output ports are not available); after the solar panels charging, it will re-output when the battery will return to 12.6V(default).

Q: Why does the controller display 14.4V?

A: If the solar charge controller is set to 12V, when the battery voltage reaches 14.4V or 14.5V, the solar charge controller will stop charging and play a protective role. If it does not enter the floating state, please don't worry, the solar charge controller has a voltage limit value, will be not charge if the battery voltage reaches to 14.4V or 14.5V.

Q:How is it set to charge battery during the day and turn on at dusk?

A: Press the [DOWN]button to ON/OF load manully at main display (The load can't be switched manually in the light control state.)

There are 3 options for the working mode.

Mode 1 : [24HR] >> Load output 24 hours

Mode 2 : [1-23HR] >> Load on aftersunset and dosed after setting hours

Mode 3 : [0H] >> Dusk to Dawn

60A PWM Solar Panel Charge Controller



Tips

  1. Charge Controller should connect in the order of 1)Battery array 2)Solar panels 3)DC load .The disassembly sequence is contrary to the wiring order.
  2. Let the children keeps far away from the storage battery and the controller.
  3. Make sure batteries's voltage between 9V-15V for 12Volt system and 18V-30V for 24Volt system so that the Charger controller can recognize the normal battery type and system in first connection.
  4. Parameter Setting Rules:Floating voltage > Low voltage reconnect > Low voltage discharge
  5. The solar controller will stop output when the battery under 10.7V(adjustable).The LCD will be blank when the battery under 8V and it will re-output when the battery up to the 12.6V(adjustable).
  6. Install the Charger controller to the battery as close as possible to avoid voltage and power dropping caused by overlong wire and affect normal voltage judgment.
  7. Connect the inverter (DC / AC) to the battery. DO NOT connect to the solar controller.
  8. The LCD display has an error of 0.2 V- 0.3 V, but this is normal .Do not open the heat sink of the solar controller without permission.


PACKAGE LIST

1 x 60 amp Charge Controller
1X English User Manual
